Trailer Depot of Sarasota is proud to offer boat trailers made by Magic Tilt. Magic Tilt has been building high-quality boat trailers since 1953. As a family owned and operated business, they are located in Clearwater, Florida and have a strong presence in the Southeast. Magic Tilt also ships nation-wide and internationally. Magic Tilt excels in building aluminum and galvanized steel trailers designed for salt water applications, including:
Kayak (tandem, quad)
PWC (single, tandem, quad)
Skiff
Pontoon / Tri-toon
John Boat
Airboat
Standard V-hull
Catamaran
Cradles
Dollies
Row boat (Crew)
Trailer Depot of Sarasota stocks a wide selection of Magic Tilt trailers from the smallest personal water craft up to 6,000-pound capacity 26 footers. Additionally, we can custom order any size and configuration to meet your individual requirements. Most special orders can be filled in less than two weeks. Please contact our knowledgeable staff to help you select the perfect Magic Tilt trailer for your needs. All of the aluminum boat trailers we stock are equipped with:
Aluminum I-beams and cross members
Stainless steel spindle sleeves
Submersible LED lights
HD winch with strap
Bow eye safety chain
HD guide poles (ALS series only)
Stainless steel bearing protectors
Aluminum load-bearing fenders
Heat-shrink wire connectors
Tongue jack
Disc brakes (tandem-axle trailers)
Dual towing safety chains
Additionally, all full-sized boat trailers are equipped with the following upgrades:
Torsion axle(s)
Carpeted bunks
Stainless steel hardware
Bow boards (6K and up)
Radial tires
Below are the trailers normally stocked at Trailer Depot.
Various sizes and configurations available.
ALS SERIES – SINGLE AXLE
| MODEL | APPLICATION | # AXLES | BOAT LENGTH | CARRY CAPACITY | TOTAL WIDTH | TOTAL LENGTH | BRAKES | TIRE SIZE |
| ALS1617N | STANDARD/JOHN/SKIFF | ONE | 14′ – 16′ | 1700 LB | 82″ | 17′ 6″ | NO | 175/80R13C |
| ALS1728 | STANDARD | ONE | 15′ – 17′ | 2800 LB | 102″ | 19′ 8″ | NO | 205/75R14C |
| ALS1928 | STANDARD | ONE | 18′ – 19′ | 2800 LB | 102″ | 21′ 8″ | NO | 205/75R14C |
| ALS2038 | STANDARD | ONE | 18′ – 20′ | 3800 LB * | 102″ | 22′ 8″ | NO * | 225/75R15D |
ALS SERIES – DOUBLE AXLE
| MODEL | APPLICATION | # AXLES | BOAT LENGTH | CARRY CAPACITY | TOTAL WIDTH | TOTAL LENGTH | BRAKES | TIRE SIZE |
| TALS2044 | STANDARD | TWO | 18′ – 20′ | 4400 LB | 102″ | 22′ 8″ | YES | 175/80R13C |
| TALS2244 | STANDARD | TWO | 20′ – 22′ | 4400 LB | 102″ | 25′ | YES | 175/80R13C |
| TALS2260 | STANDARD | TWO | 20′ – 22′ | 6000 LB | 102″ | 25′ | YES | 215/75R14C |
| TALS2460 | STANDARD | TWO | 22′ – 24′ | 6000 LB | 102″ | 27′ | YES | 215/75R14C |
| TALS2660 | STANDARD | TWO | 24′ – 26′ | 6000 LB | 102″ | 29′ | YES | 215/75R14C |
PWC – SINGLE & DUAL
| MODEL | APPLICATION | # AXLES | BOAT LENGTH | CARRY CAPACITY | TOTAL WIDTH | TOTAL LENGTH | BRAKES | TIRE SIZE |
| PWCV1250A (ALUMINUM) | SINGLE PWC | ONE TORSION | 8′ – 12′ | 1250 LB | 60″ | 172″ | NO | 480x12B |
| DWC2500A (ALUMINUM) | DUAL PWC | ONE TORSION | 8′ – 12′ | 2500 LB | 102″ | 201″ | NO | 175/80D-13C |
JOHN / SKIFF / FLATS
| MODEL | APPLICATION | # AXLES | BOAT LENGTH | CARRY CAPACITY | TOTAL WIDTH | TOTAL LENGTH | BRAKES | TIRE SIZE |
| CA1412 (ALUMINUM) | JOHN/SKIFF/FLATS | ONE | 12′ – 14′ | 1200 LB | 60″ | 16′ 10″ | NO | 480x12B |
| CA1515 (ALUMINUM) | JOHN/SKIFF/FLATS | ONE | 14′ – 15′ | 1500 LB | 76″ | 18′ 10″ | NO | 175/80R13C |
| ALS1617 (ALUMINUM) | SKIFF/FLATS/BAY | ONE | 14′ – 16′ | 1700 LB | 93″ | 17′ 6″ | NO | 175/80R13C |
KAYAK
| MODEL | APPLICATION | # AXLES | BOAT LENGTH | CARRY CAPACITY | TOTAL WIDTH | TOTAL LENGTH | BRAKES | TIRE SIZE |
| KA0010 | DUAL KAYAK | ONE | 8′ – 16′ | 1200 LB | 73″ | 14′ 10″ | NO | 480x12C |
